Diagram of Judgment Method of Helical Gear Rotation

According to the different tooth rotation directions, helical gears can be divided into left-handed and right-handed. Then, how to see its rotation direction and how to judge it? What is the method for determining the rotation direction? Is there an illustration?Follow belowEP gear processing Come and find out.

Diagram of helical gear rotation judgment method:

The gear axis is vertical, the left side of the spiral line is a left-handed helical gear, on the contrary, if the right side of the spiral line is high, it is a right-handed helical gear, as shown in the figure below.

Use left and right hand methods to judgehelical gearThe rotation direction is actually the same, so I won’t repeat the description here. If you want to know, you can consult our technology for free.

The above is the related description of the helical gear rotation judgment method diagram, including but not limited to, for your reference and understanding, you can consult EP for free if you are unclear or related to gear processing requirements.
