Explanation of the Machining Principle of Small Module Gear Milling

Principle of tooth milling:

The small module gear is used on the gear milling machine with contour andgearGear milling cutters with exactly the same tooth groove shape are fed along the workpiece axis. Each tooth groove is milled, the workpiece is indexed once, that is, one tooth is rotated, and all tooth grooves are milled in turn.

Whether it’s a modified cycloid gear orInvolute gear, The principle is the same.

There is no standard set of milling cutters for milling correction cycloid gears, which must be based onGear parametersDesign a special milling cutter.

Gears with different modules, gears or the same module with different numbers of teeth need to be milled with a special milling cutter.

Involute gear milling uses a set of milling cutters to mill gears with the same module but different numbers of teeth.

The above is the explanation of the principle of small module gear milling processing, including but not limited to, if you have more questions or related needs, you can consult EP Technology for free.
